China High Quality for Mode 3 32A Single Phase 3phase EV Charging Station Manufacture and Factory

High Quality for Mode 3 32A Single Phase 3phase EV Charging Station

Short Description:

High Quality for China EV Charging Station Manufacturer, Wall Box Type2 Type1 EV Charging Station, Definitely should really any of these objects be of curiosity to you, make sure you allow us to know. We will be delighted to provide you a quotation on receipt of one's thorough specifications. We've our personalized professional R&D enginners to meet any with the requriements, We look forward to receiving your enquires soon and hope to have the chance to work together with you inside the future. Welcome to take a look at our organization.

Output Power: 7kW, 11kW, 22kW

Communication Protocol: OCPP 1.6J (2.0 compatible)

Input Current: 16A, 32A

Input Voltage: 230±10% (1 phase), 400±10% (3 phase),

RCD: Type A+DC6mA

IP, IK : IP65, IK08

External Communication: LAN+4G (Optional)+WIFI (Optional)

Display: 4.3" LCD Screen (Touch Screen optional)

Cable Dimension: 350x250x175mm

Socket Dimension: 350x250x130mm

Send email to us Download as PDF

Product Detail

Product Tags

We’ve got state-of-the-art tools. Our goods are exported towards the USA, the UK and so on, enjoying a superb standing among consumers for High Quality for China Mode 3 32A Single Phase 3phase EV Charging Station, We’ve been trying to get for substantial cooperation with sincere clients, obtaining a brand new induce of glory with customers and strategic partners.

Type 2 16A 11kw EV Charger for Electric Vehicle Charging

JNT-EVC10 Series

Model Name	EVC10-07C1S	EVC10-07C1C	EVC10-22C1S	EVC10-22C1C
Input Voltage	230±10% （1 phase）		400±10% （3 phase)
Frequency	50Hz
Input Current	32A
Output Current	32A
User Authentication	RFID (ISO 14443)
External	LAN (optional) + 4G (optional) or Wi-Fi (optional)
Internal	OCPP 1.6 JSON (OCPP 2.0 compatible)
Operating Temperature	-22˚F~122˚F(-30˚C~50˚C)
Humidity	Max. 95% RH
Altitude	≦ 2000m
IP Level	IP65 for box
Cooling Method	Natural Cooling
Dimension(WxDxH)	350x250x175mm	350x250x130mm	350x250x175mm	350x250x130mm
Charging Outlet	One Charging socket	5m charging cable	One Charging socket	5m charging cable
CCID	Type A + DC6mA
Multiple Protection	Over current, Under voltage, Over voltage, Residual current, Surge protection, Short circuit, Over temperature, Ground fault, Current leakage protection
Certificate	IEC 61851-1, IEC61851-21-2
Safety	CE
Wireless Certificate	RED
Charging Interface	IEC 62196-2, Type 2 Plug

The most compact design on the market with the highest performance, intelligent charging system for plug-in vehicles, designed for semi public and business charging locations. Easy to install, easy to use and easy to enjoy.

It is a new and improved second generation design, incorporating internal leakage protection. Which make installation easier and more economical. The charger connects with management platform, which makes it smart and enables multiple user access with a simple RFID card or Wallbox mobile app.

Personalised support service: Dimensions 350x250x175mm. 4.3″ untouchscreen with custom interface and adjustable charging power from the display. Can set up up to four different recharging schedules to coincide with lower energy costs.

Type 2 16A 11kw EV Charger for Electric Vehicle Charging1
